BLISS SQUARE
Interior Compact Wall Sconce
Bliss Square produces a simple unbroken square of illumination from its crisp, boxed form. The halo of light emits from a square frosted acrylic lens and provides comfortable, easy on the eyes illumination from all angles. The painted aluminum front face offers a unique opportunity for a pop of color.
Use Bliss Square for wayfinding or in hallways for eye-catching illuminated room markers. This ADA wall sconce features a seamless acrylic lens that is easy to clean. Bliss Square is offered with static white or dim-to-warm source options. The dim-to-warm LED source gives everyone increased control of their environment by allowing them to shift to warmer color temperatures as the lighting is dimmed. This creates a cozy and relaxing atmosphere.
- Aluminum housing and front fascia
- Seamless, extruded acrylic luminous diffuser
- Static white and dim-to-warm source options
- Optional 90CRI source
- Dimmable using 0-10V or phase-cut controls
- Smooth outer surfaces for improved cleanability
- BAA (Buy American Act) and BABA (Build American, Buy America) compliant
MODELS:
CB7010
Integral
Spec Sheet Install IES BIM File
Anti-microbial coating on GLWT and VBLK changes the finish texture.
Please contact factory
Painted
- Custom output or color temps
- Custom powder coat color
- Backlit custom cutout on front for wayfinding
Product Specifications & Documents
CB7010
Integral
- H
- W
- D
- 4-3/4” (121 mm)
- 4-3/4” (121 mm)
- 3-7/8” (98 mm)
- CCT
- 3000K
3500K
4000K
1800K-3000K
2700K-4000K
- Lumens
- L: 1100 H: 1600
L: 1150 H: 1600
L: 1150 H: 1650
L: 825 H: 1200
L: 950 H: 1250
- Watts
- L: 13 H: 19
L: 13 H: 19
L: 13 H: 19
L: 14 H: 20
L: 14 H: 20
- Driver
- Integral
- Control
- 0-10V to 1%
- Listings
- Damp
ADA
VIDEO
Bliss Round & Square Sconces
Bliss Round and Bliss Square are small luminous geometric forms; their painted aluminum front faces offer a unique opportunity for a pop of color. Use them for wayfinding or in hallways for eye-catching illuminated room markers.
Learn more about our made in America productsCompact ADA Square Wall Sconce
Bliss Square produces an unbroken square of illumination from its compact, boxed form. The shallow, frosted acrylic lens provides comfortable, easy-on-the-eyes illumination from all angles.
View the Entire Bliss FamilyBliss Square, One of our Newest Sconces
These unique luminaires can be helpful tools when designing layers of light to create a soft ambiance or add decorative and functional wayfinding illumination throughout all facilities.
